Descripcion
Technical Specifications:
SteelHead CX: Model Specifications
| Branch office SteelHead | Mid-Size Office SteelHead | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | CX255 Series | CX570 Series | CX770 Series | |||||||
| Configurations | U | L | M | H | L | M | H | L | M | H |
| Profile | Desktop | |||||||||
| Upgradeable To | 255 L/M/H | 255M/H | 255H | – | 570 M/H | 570-H | – | 770-M/H | 770H | – |
| Optimized WAN Capacity | 2Mbps | 6Mbps | 6 Mbps | 10 Mbps | 10 Mbps | 10 Mbps | 10 Mbps | 20 Mbps | ||
| Optimized TCP and UDP flows | 50 | 75 | 150 | 230 | 250 | 400 | 650 | 900 | 1,500 | 2,300 |
| QoS Bandwidth(a) | 4 Mbps | 12 Mbps | 12 Mbps | 20 Mbps | 20 Mbps | 45 Mbps | 45 Mbps | 45 Mbps | ||
| QoS Rules/Classes(b) | 300 | 500 | 1000 | 1,000 | 1,000 | |||||
| Data Store Capacity | 50GB | 70 GB SSD | 150 GB SSD | |||||||
| Storage Fault Tolerance | – | – | – | |||||||
| Hot Swappable Drives | – | – | – | |||||||
| RAM | 2GB | 2 GB | 4 GB | |||||||
| Expansion Slots (PCI-e)(f) | – | – | – | |||||||
| Onboard Bypass Ports (Copper) | 2 | 4 | 4 | |||||||
| Max. # of Bypass Ports | 2 | 4 | 4 |
| Large Office or Data Center SteelHead | ||||||||
|---|---|---|---|---|---|---|---|---|
| Model | CX1555 Series | CX5055 series | CX7055 series | |||||
| Configurations | L | M | H | M | H | L | M | H |
| Profile | 1U | 2U | ||||||
| Upgradeable To | 1555-M/H | 1555H | – | 5055 H | – | 7055-M/H | 7055-H | – |
| Optimized WAN Capacity | 50 Mbps(g) | 50 Mbps(g) | 100 Mbps(g) | 200 Mbps | 400 Mbps | 622 Mbps | 1 Gbps | 1.5 Gbps(h) |
| Optimized TCP and UDP flows | 3,000 | 4,500 | 6,000 | 14,000 | 25,000 | 75,000 | 100,000 | 150,000 |
| QoS Bandwidth(a) | 100 Mbps | 100 Mbps | 100 Mbps | No limit | ||||
| QoS Rules/Classes(b) | 2,000 | 2,000 | 2,000 | 4000 | ||||
| Data Store Capacity | 400 GB | 400 GB | 320 GB SSD | 640 GB SSD | 1.6TB SSD | 2.4 TB SSD | 4.8 TB SSD | |
| Storage Fault Tolerance | RAID(d) | RAID(e) | ||||||
| Hot Swappable Drives | 4 | 4 | 4 | 10 | 12 | 17 | 18 | |
| RAM | 8 GB | 16 GB | 32 GB | 48 GB | 64 GB | |||
| Expansion Slots (PCI-e)(f) | 2 | 4 | ||||||
| Onboard Bypass Ports (Copper) | 4 | 4 | ||||||
| Max. # of Bypass Ports | 12 | 20 |
NOTE: All WAN Capacity / Bandwidth, TCP Connections and UDP flows, and QoS specifications listed are maximums and may not be achieved in all environments. The WAN capacity limit is enforced on outbound optimized traffic. Inbound optimized WAN traffic is not capped(a)Recommended maximum outbound QoS shaping capacity(b)Total of classes plus rules(c)Includes HDD’s with SSD’s(d)RAID10 configuration for HDD, Data store uses fault tolerant striped (FTS) configuration for SSD/HDD(e)RAID1 configuration for HDD, Data store uses fault tolerant striped (FTS) configuration for SSD(f)Optional Network Bypass cards: Dual and Quad LX and SX GigE Fiber GigE, Quad Copper GigE, 10GbE SR/LR(g)Requires RiOS 7.0.4 onwards(h)No enforced optimized WAN bandwidth limit
SteelHead CX: Power & Physical Specifications
| Model | CX255 Series | CX570 Series | CX770 Series | CX1555 Series | CX5055 | CX7055 |
|---|---|---|---|---|---|---|
| Dual Power Supplies | – | – | ||||
| Power [Watts] (Typical) | 30 | 45 | 50 | 175 | 375 | 420 |
| BTU | 102 | 145 | 165 | 605 | 1280 | 1425 |
| Temperature(ii) | 0 – 45 deg C / 32 – 113 deg F (Operating) -40 – 65 deg C / -40 – 149 deg F (Storage) |
0 – 45 deg C / 32 – 113 deg F (Operating) -40 – 65 deg C / -40 – 149 deg F (Storage) |
10 – 40 deg C / 50 – 104 deg F (Operating) -40 – 65 deg C / -40 – 149 deg F (Storage) |
|||
| Relative Humidity(i) | 20% – 80% non-condensing (Operating) 5% – 95% non-condensing (Storage) |
|||||
| Operating Acoustic noise(Typical) | 45 dBA | 62 dBA | 65 dBA | |||
| System Dimensions (LxWxH)(iii) | 13.0″x8.0″x1.73″ 330x204x44mm |
25.4 x 17.2 x 1.71 in 645.4 x 436 x 43.5 mm |
25.4 x 17.2 x 3.43 in 645.4 x 436 x 87.1 mm |
|||
| Packaging Dimensions | 17.7 x 12.2 x 7 in 450x310x180 mm |
36.25 x 23.38 x 12.5 in 920.8 x 593.7 x 317.5 mm |
||||
| Max Weight (without packaging) | 5.5lbs 2.4kg |
6 Lbs 2.7 Kg |
36 Lbs 16.36 Kg |
52 Lbs 23.6 Kg |
54 Lbs 24.5 Kg |
|
| Rail Information | Optional mounting ears. Orderable spare part RMK-010 |
Included spare part RMK-010, Orderable RMK-016 |
Mounting raiincluded. Orderable spare part RMK-002A |
(i)Operating altitude up to 10,000 feet except in China 6,562 feet (2,000m)(ii)In China- for use in non-tropical locations(iii)Length is without bezelThe availability, export or re-export of these products or specific features are subject to the export laws and regulations of the U.S., EU, Singapore, and the laws and regulations of any applicable foreign agency or authority.
